3751【PDF 1/1 页】BOX BNC F/F W/CVR 1.5X1.13X0.88"

Pomona

Model 3751

Miniature Size Aluminum Box With

Cover BNC Female/Female

MATERIALS:

Connector: BNC (F)

Body: Tarnish Resistant Plating, Center Contact: Gold Plated Beryllium Copper

Marking: “Pomona 2451”

Solder Turret Terminal Screws: Steel, 4 ea. #4-40

Shielded Housing: Die cast aluminum, alloy A380 or A384

Finish: Blue baked enamel per Federal Standard 595 #25109 over Phosphoric Etch per MIL-C-15328.

Marking: “Pomona Electronics Calif.”

Cover: .040 thick aluminum 1100-H14

Finish: Clear anodized per MIL-A-8625

Marking: “Pomona 3751”

RATINGS:

Operating Voltage: Inner conductor/Shield: 500 VRMS Max.

Operating Temperature: -55oC to +150oC

Nominal Impedance: 50 Ohms

ORDERING INFORMATION: Model 3751

All dimensions are in inches. Tolerances (except noted): .xx = ±.02” (,51 mm), .xxx = ± .005” (,127 mm).

All specifications are to the latest revisions. Specifications are subject to change without notice.

Registered trademarks are the property of their respective companies. Made in USA

6/9/99

SY/EH/LS

Sales: 800-490-2361 Fax: 888-403-3360

Technical Assistance: 800-241-2060

Pomona ACCESS 90202 (800) 444-6785 or (425) 446-6010

More drawings available at www.pomonaelectronics.com

S:\Engineering \Release\DataSheets\FlukeDataSheet\d3751_1_01.doc

Page 1 of 1
